Stud welding with ceramic ferrule, weld area Ø 6 – 25 mm
Short-cycle stud welding, weld area Ø 3 – 12 mm
Shielding gas stud welding, weld area Ø 3 – 16 mm
Weight 350 kg Weld area Ø 6 – 25 mm
Welding gun connections 1 pcs
Max. current 3500 A
Infinitely variable current setting range 300 – 2600 A
Infinitely variable time setting range 20 – 2000 ms
Shielding gas pre-flow time 100 – 2000 ms
Memory capacity 20 Parameter sets
Max. studs/min. for … Ø 50 / 6 ; 6 / 25 mm
Mains connection: 50/60 Hz, three-phase current 230 / 400 V
Mains connector for 400 V 125 A
Mains cable 5 / 16 m/mm²
Slow-blow mains fuse 80 / 100 A
Mains input power at …% DC 8 / 13 / 100 ; 187 / 145 / 52 kVA
Mains voltage tolerance – 15 / + 6 %
Protection class IP 23
Type of cooling F
Housing dimensions (L x W x H) 950 x 605 x 860 mm
Handle 1
Crane lugs 2
For more information please contact us.
